ToolkitRC M9 LiPo 1-8S 25A Charger DC 7-35V
ToolkitRC M9 LiPo 1-8S 25A Charger DC 7-35V
Regular price
$135.99
Regular price
Sale price
$135.99
Unit price
/
per
Couldn't load pickup availability
• Multi angle display: 0-85 degree screen angles for easy viewing
• Massive 600W output: 2-8S capable, with automatic cell balancing
• Dual USB fast charging: 65W maximum USB-C/USB-A output
• All in one functionality
• IPS wide-angle display: ibrant 2.4 inch color screen, viewable even in direct sunlight
SPECS
| Charger | Input Voltage | 7-35V@MAX 25A |
| Type |
LiPo LiHV LiFe Li-ion@1-8S NiMh @1-20S Pb @1-12S |
|
| Charge Power | 0.1-20A@600W | |
| Discharge Power |
0.1-20A@600W External 0.1-3A@20W Normal |
|
| USB |
5-20V MAX 65W@TYPE-C TYPE-A
Protocol PD 3.0/PD2.0/PPS/QC4/QC3.0/QC2.0 AFC/FCP/SCP/PE2.0/PE1.1/SFCP/VOOC |
|
| Measure | PWM | 500us-2500us @20-1000Hz |
| PPM | 880us-2200us*8CH @20-50hz | |
| SBUS | 880us-2200us*16CH @20-100Hz | |
| Voltage | 1.0V-5.0V @8S | |
| Internal resistance | 1-100mR @8S | |
| ESC | 0.1A-25A @MAX 600W | |
| Output | PWM | 880us-2200us @20-400Hz |
| PPM | 880us-2200us*8CH @50hz | |
| SBUS | 880us-2200us*16CH @74Hz | |
| Power supply | 0.11-25A@1-30V Mode:CC+CV | |
| General | TF Card | 128Mb-16Gb |
| Product size | 110*70*39mm | |
| Product weight | 240g | |
| Package size | 135*81*44 mm | |
| Package weight | 330g | |
| LCD | IPS 2.4”320*240 pixel |
